Trimble TDL450B UHF Radio

With advanced wireless Bluetooth communication and rugged design, the TDL450B UHF radio enables easy integration with GNSS receivers, even in harsh environments.

• Easy setup and configuration: Connecting via Bluetooth to GNSS receivers reduces setup complexity and reduces a common failure point in radio systems.
• Built to last in harsh conditions: An IP67 rating and military-spec design ensures reliable operation and the ability to work in higher ambient temperatures. Get more work done in all weather.
• Solve challenges in the field: Provides access to diagnostic data with a high over-the-air link rate, enabling you to solve signal strength issues and make adjustments to stay productive.

The TDL450B includes the latest Trimble radio technology, providing you with optimal performance in the field.

• Frequency range -- 403-473 MHz
• Over-the-air link rate -- 4,800 to 19,200 bps
• Configurable maximum Tx power -- Up to 35 W
• Corrections for GNSS receivers -- 1 Hz RTK
• Environment -- IP67 rated
• Vibration -- MIL-STD-810F
• Full-function user interface -- Easy to configure and troubleshoot, with adaptable batteries that allow you to dial up or use a lower power outlet depending on field size and needs.
• Use with Trimble GNSS receivers -- Capable of broadcasting, repeating and receiving real-time data used by Trimble GNSS receivers. Mount it on the same tripod as the receiver or on its own tripod.

The Trimble 750 GNSS Modular Receiver is suitable for various industries, including:

• Trimble R980 -- The premium GNSS solution to boost productivity for surveyors.
• Trimble R12i -- Unmatched GNSS performance to elevate survey productivity.
• Trimble R780 -- Bringing precision to challenging survey projects.
• Trimble R750 Model 2 -- For RTK-level precision and more connectivity.
• Trimble R580 -- Access to professional-grade positioning accuracy.
